Prefabricated Rubber Running Track System for School Running Track & Field | NOVOTRACK

group name: College | University | School Rubber Running Track

Min Order: 1 piece

brand name: NOVOTRACK

model: NTTR

Nearest port for product export: Port of Tianjin, China

Delivery clauses under the trade mode: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT

Acceptable payment methods: T/T, L/C

update time: Thu, 21 Nov 2024 17:39:49 GMT

contact supplier

Paramtents

Place of Origin Tianjin, China
Thickness 8-15mm
Color Wide range of color options
Application Running Track & Field

Packging & Delivery

Min Order1 piece

Briefing

NTTR is the ideal athletic track surface for facilities dedicated to both competition and training because it guarantees athletes the perfect combination of shock absorption, vertical deformation and energy return. Prefabricated Rubber Running Track (Outdoor Running Track) is A synthetic surfacing system comprised of a pre-fabricated rubber mat laid in a two-component polyurethane adhesive installed on a properly prepared asphalt or concrete substrate and fluid applied membrane waterproofing system.

Detailed

Product Description

Prefabricated Rubber Running Track System

NTTR

NOVOTRACK athletics tracks are prefabricated, made with vulcanized rubber under controlled factory conditions. NTTR is the ideal athletic track surface for facilities dedicated to both competition and training because it guarantees athletes the perfect combination of shock absorption, vertical deformation and energy return.

Foundation

Before the construction of a prefabricated rubber track, the ground must meet certain hardness standards. Therefore, the foundation of the prefabricated rubber track must be properly cured.

Surface Layer

The upper surface layer with better anti-skid and drainage.The top layer is wear-resistant, protecting the roll and providing

UV resistance, anti-aging,

increased friction, and anti-slip effects.It's made of natural rubber.

Base Layer

The lower layer is a concave air cushion arranged side by side, with an average of 8400 holes and grooves per square meter.The bottom layer is honeycomb-designed to maximize anchoring density.

Adhesive

The bonding strength is further enhanced, as the prefabricated rubber running track used with rigid adhesive solve the issue of traditional adhesive failing before the surface layer.solid and reliable overall

Properties

The properties of this product perfectly achieve the international standards.

Test Items	National Standard Parameter Requirements	Measured Parameters	Achieve Standard
shock absorption/ (%)	25～50	38.8	Qualified
vertical deformation/ (mm)	0.6～2.5	1.8	Qualified
Anti-skid value/(BPN, 20℃)	≥47 (wet test)	49	Qualified
Tensile Strength/ ( MPa)	≥0.5	0.76	Qualified
Elongation at break/(%)	≥50	162.3	Qualified
Flame retardant/ (class)	Ⅰ	Ⅰ	Qualified

Technical Factors

NovoTrack products have passed a series of environmental indicators testing, obtaining Type II environmental certification. They are children-friendly products, meeting both physical and chemical indicators according to national standards GB36246-2018, GB/T14833-2020, and GB/T22517.6, making them truly eco-friendly products.
